Suitable for food industry, chemical industry, Commodity industry, pharmaceutical industry and other packaging.(soap,hardware, bearing,INSTANT NOODLES ,COSMETICS,brushtooth,PERFUME,drink,toy,body lotion ,body wash, )
Application:
This Semi-automatic bottle packing shrink sleeve wrapping machine is suitable for wrapping pop-cans, mineral water, bottles beer, drinks, etc, with bottom-tray or without bottom-tray, working with SN-5040A jet PE-film shrink tunnel or other PE shrink tunne
Feature:
> Double size fan carrying system ensur the perfect of sealing.
> Imported AC contractor, the temperature be controlled by automatic.
> Imported frequency converter, stepless speed regulating.
> Super cooling system to ensure the perfect shape of products quickly ofter shrinking.
> The control panel be operated with safe and simple.
> The imputing position can be adjustable precision base on the size of products.
> Up and down large power fan system to assure the excellent effect of shrinking in onetime.
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Main technical parameter
Model | 5038B | Model | 5040A heater shrink |
Power supply | 220-240V, 50-60Hz;1.8KW | Power supply | 3phase 220V/380V 50-60HZ |
Capacity | 2-6pcs/minute | Heater power | 20KW Adjuster |
Sealing time/shrink time | 0.5-1.5s, 0-0.6s | Conveyer speed | 0-10m/minute |
Conveyor loading | 25kg | Tunnel size(L*W*H) | 1500*500*460MM |
Film width | Max. 550mm | Conveyer loading | 30KGS MAX. |
Film thickness | 0.04-0.12mm | Shrink film | PE,POF,PVC |
Max. packing dimension(L*W*H) | 450 x 270 x 350mm | Machine weight | 450KG |
Min. packing dimension(L*W*H) | 250 x 60 x 60mm | Machine size | 2500*820*1680MM |
Machine size(L*W*H) | 1020 x 830 x 1980mm | ||
Packing size | 1120*940*2000mm |
