SN-G600 GRANULE MULTI LINE PACK BAG IN BAG PRODUCTION LINE
Suitable for food industry, chemical industry, Commodity industry, pharmaceutical industry and other packaging.(MICROWAVE POPCORN,NUTS, CANDY ,OATMEAL CEREAL ,SNACK,SUGAR ,RICE,COFFEE BEAN,BEAN,PEANUT,SALT,CHIPS,RAISINS)
- category : Granule Packing Machine
- email : delia@snpkmachinery.com
- email : tony@snpkmachinery.com
- email : sales@snpkmachinery.com
- mobile : +86-15958748873
- mobile : +86-15868796452
- whatsapp : +86-15958748873
- whatsapp : +86-15868796452
Applicaiton:
This production line is suitable for automatic package of small and medium bags with measurement requirements, for granules in areas of medicinet,food, daily chemical and other industry, such as Chinese medicine infusion ,coffee, white sugar, monosodium glutamate , pellet, small granular pharmaceutical preparation.
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
* Please select the style of packag you need, or provide a sample of your package |
||||
Main technical parameter
| Pouch length range | 45-200mm |
| Pouch width range | 23-60mm |
| Capacity | 20-60(depend on bag length and material) |
| filling capacity | 1-50ml |
| Max film width | 700mm |
| Power | 380V/220V 50/60HZ 16KW |
| Air consumption | 1 m³/min |
| Dimension | 1875*1500*3200mm |
| Weight | 2500kg |
Pouch packing machine
| Working station | 8-working station |
| Pouch material | Laminated film PE,PP ETC |
| Pouch pattern | stand-up, flat |
| pouch size | L100-350mm ,W:90-200mm |
| speed | ≤60 pouch/min |
| power | 380V/220V 50/60HZ 4KW |
| Compress Air | 0.6m³/min |
| Weight | 1100kg |
