NJP260 AUTOMATIC PHARMACEUTICAL OIL LIQUID CAPSULE FILLING MACHINE

Suitable for medicine granule capsule,powder capsule, oil liquid capsule

Application:

Fill oil liquid product, solution, suspension liquid or paste into hard gelatin capsule.


Features:

1. NJP Series Liquid automatic capsule filling machine, ensure the filling quantity difference, measuring precision, control

within the ±1.5%,

2. can pack oily liquid, solution, suspension liquid or paste, etc.

3. The machine adopts automatic frequency control of motor speed, convenient and intuitive operation.

4. The machine as the new century a new convenient dosing filling way and the idea, is the ideal equipment in the pharmaceutical,

food, health care products industry.








Technical parameter :

Specifications type NJP-260
Output 260 Capsules/min
Machine weight 900Kg
Machine Dimensions 1020×860×1970mm
Power Supply AC 380V 50Hz
Filling Percentage ≥99.5%
Noise ≤75dBA
Content Uniformity liquid 300mg above≤±3%
compressed air 0.06m3/min 0.3Mpa
Vacuum -0.02~-0.06 MPa
Motor power 5.75kw
Water flow 250L/h
Inner diameter of inlet pipe 20mm
Inner diameter of drain pipe 27mm
Displacement 300m3/h
Size for Capsule Capsule size 00#-5# and safety capsule A-E
