SEMIAUTO CAPSULE FILLING MACHINE

Suitable for medicine granule capsule,powder capsule, oil liquid capsule

Application:

The machine is adopted programmable control system, touch panel operation, stepless transduction speed shift with output display function. It can automatically complete the action of position, separation, flling, locking, etc. The fling dosage is accurate, and the operation is very convenient. The overall machine is made of good quality stainless steel, and the machine is suitable for capsules which flld with powder and pellet.
















Technical Parameter :

Model DTJ-C
Output Capacity 10000-20000pcs/h
Capsule Size #000-#4
Filling Dosage Ajustable
Voltage 380/220V 50/60Hz
Air pressure 0.03m3/min 0.7Mpa
Power 2.2kw
Weight 350kg
Dimension 1290*685*1600mm
